Non Rising Stem Gate Valve

2″-5″
2,000-10,000psi
Basic Design: API 6A
Test & Inspection: API 6A

Design Features

• Metal to Metal seat, Parallel Gate and seal with ring


• Slab Gate with Hard Face


• Positive upstream and downstream seal


• Automatic Cavity Pressure relief


• Piggable

• Basic Design: API 6A


• Working Pressure (psi) 2M, 3M, 5M.10M


• Main nominal size (in) 2-1/16, 3-1/8 (3-1/16), 4-1/16

• Material: API Rating AA, BB, CC, DD, EE, FF, HH.


• Body: Carbon Steel, Alloy Steel, Stainless Steel, Duplex S.S.


• Manufacturing to NACE MR0175 upon request
